Real-Time Convolver™ Software

(This software is no longer support)

The Real-Time Convolver is a hardware / software add-on to the Hypersignal®-Acoustic software package which implements very long FIR filters (VLFFs) in real-time. VLFFs can be created by Hypersignal-Acoustic software using equalization functions, FIR/IIR digital filter design, difference equations waveform editing, or imported from external waveform files. VLFFs can then be downloaded to supported hardware in ASCII or binary form using Hypersignal-Acoustic software or DirectDSP software.

For more information about the Real-Time Convolver, please click here to download the Real-Time Convolver Users Manual.

Real-Time Convolver Feature Summary

  • Using Sig32C-4 or National Instruments AT-DSP2200 board (see below), up to 10,000 pt. impulse response can be applied in real-time at 44.1 kHz stereo (one filter applied to both channels)

  • Binaural filtering or mono operation

  • 11.025, 16, 22.05, 32, 44.1, 48, 51.2 kHz rates supported

  • Waveform file mode included, for accelerated file-based processing

  • Software consists of Hypersignal-Acoustic, plus Real-Time Convolver™

Hardware Options Supported by the Real-Time Convolver

  • 8-chan input, 8-chan output sigma-delta Sig32C-8 board with 82 dB typical dynamic range, 80 MHz DSP32C, 128k x 32 zero-wait SRAM, interboard sampling, and interboard communication bus

  • 4-chan input, 4-chan output sigma-delta Sig32C-4 board with 92 dB typical dynamic range, 80 MHz DSP32C, 128k x 32 zero-wait SRAM, expansion 512k x 32 0-wait SRAM (640k x 32 SRAM total), and 16-bit external digital I/O

  • National Instruments AT-DSP2200 board, with 2-channel sigma-delta analog I/O, 92 dB typical, 384k x 32 zero-wait SRAM

  • 2-chan input, 2-chan output sigma-delta Ariel DSP-32C board with 90 dB typical dynamic range, 50 MHz DSP32C, 64k x 32 zero-wait SRAM
